Fire Extinguisher Filling Equipment
#550-200: Dry Chemical Powder Handling System
Utilities Required To Operate:
- 80 psi @ 4CFM of pre-regulated shop air
- Scale for weighing fire extinguisher during fill process
**Picture shown with optional universal fill cone part number 550-203**
- Replacement Quick Disconnect Nipple: 110-013
- Replacement Quick Disconnect Coupler: 110-015
- Replacement Discharge Hose (3-foot long): 200-120
- Replacement Discharge Screen: 160-023
- Replacement Manifold: 210-555
- Replacement Pressure/Vacuum Gauge: 140-011 / 140-012
- Replacement Venturi: 190-001
$1,695.00 | SKU: 550-200
The Ultimate Dry Chemical Fire Extinguisher Powder Handling System
Designed for in shop or mobile truck use.
Features:
- New polypropylene tub – less weight – no corrosion
- Discharge and refill in same unit
- Clean and efficient way to service portable dry chemical fire extinguishers
- Transfer rate of 1/4 Lb per second
- 150 Lb hopper capacity
- Discharge filter easily cleaned and replaceable
- Inlet pressure and outlet vacuum gauges
- 5′ long powder transfer hose
- 18″ long discharge hose with shutoff valve and coupler
- Includes set of discharge adapters
- Steel enamel painted support frame
- **Picture shown with optional universal fill cone part number 550-203**
- Foot Print: 36″H x 20″W x 20″L
- Net Weight: 60 Lbs net (empty of powder)
- Shipping Weight: 85 Lbs
